Features:

  • 1/2.7″ SC2232 CMOS sensor
  • Full HD resolution 1920 x 1080P
  • low illumination 0.01Lux
  • Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT
  • D-WDR, Motion Detection, Privacy Mask, Mirror, Flip
  • RTSP and Onvif 17.06 compatible
  • H.265/H.264 dual-stream media server
  • Easy-to-use P2P Cloud service
  • Multi web browser, PC Client, mobile APP remote access
  • Lightning protection 4000V
  • Strong water-proof housing, IP66
  • 20 pcs SMD Array IR Leds, IR distance 30-40 meters
  • 2.8 -12mm Varifocal lens
Categories: , , , ,

Description


Camera

Image Sensor

1/2.7″ Smartsens CMOS

Effective Pixels

1936(H)×1096 (V)

Electronic Shutter

AUTO

Min. Illumination

0.01Lux@F1.2(AGC ON), 0Lux IR on

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto/Manual

BLC / HLC

Support

DNR

2D/3D DNR

Other

Motion Detection, Privacy Mask,Flip, Mirror

Encode

Embedded Solution

Mstar313E+SC2232

Video Standard

H.264/H.265

Video Resolution

Main stream: 1080P@25fps, 720P@30fps

Sub stream: VGA@ 360P/CIF@25fps, etc.

Video Bitrates

500Kbps – 6Mbps, VBR/CBR

Audio Standard

G.711-u/G.711-a

IR Led

IR Led

20pcs SMD Array IR LEDs

IR Distance

30-40M IR Distance

Lens

Focal length

2.8-12 mm Varifocal lens

Zoom

4X optical

Optional Function

POE, External Audio

Network Services

Protocol

RTSP/DHCP/NTP/DST/FTP/SMTP

P2P

Yes

Web

IE , Firefox 32bit esr

Media

CMS, Android, IOS

ONVIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps, POE optional

Power Supply

12 VDC ± 10%

Power Consumption

< 5 W

Operating Temp.

-30-(+60), 10%-90%RH
