Features:

  • 1/2.7″ SC2232 CMOS sensor
  • Full HD resolution 1920 x 1080P
  • low illumination 0.01Lux
  • Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT
  • D-WDR, Motion Detection, Privacy Mask, Mirror, Flip
  • RTSP and Onvif 17.06 compatible
  • H.265/H.264 dual-stream media server
  • Easy-to-use P2P Cloud service
  • Multi web browser, PC Client, mobile APP remote access
  • With Builtin Microphone
  • Lightning protection 4000V
  • Strong water-proof housing, IP66
  • 10pcs SMD Array IR Leds, IR distance 10-15 meters
  • 2.8 mm fixed lens
Categories: , , , ,

Description

Camera
Image Sensor 1/2.7″  Smartsens CMOS
Effective Pixels 1936(H)×1096 (V)
Electronic Shutter AUTO
Min. Illumination 0.01Lux@F1.2(AGC ON), 0Lux IR on
Day/Night Auto/Color/(B/W)/Timing
WDR Digital WDR
White Balance Auto/Manual
BLC / HLC Support
DNR 2D/3D DNR
Other Motion Detection, Privacy Mask, Flip, Mirror
Encode
Embedded Solution Mstar313E+SC2232
Video Standard H.264/H.265
Video Resolution Main stream: 1080P@25fps, 720P@30fps
Sub stream: VGA@ 360P/CIF@25fps, etc.
Video Bitrates 500Kbps – 6Mbps, VBR/CBR
Audio Standard G.711-u/G.711-a
IR Led
IR Led

10pcs SMD Array IR LEDs
IR Distance

10-15M IR Distance
Lens
Focal length 2.8 mm lens
Zoom

N/A
Optional Function
POE, External Audio
Network Services
Protocol RTSP/DHCP/NTP/DST/FTP/SMTP
P2P Yes
Web IE , Firefox 32bit esr
Media CMS, Android, IOS
ONVIF 17.06 compatible
General
Network Port 1-RJ45, 100Mbps, POE optional
Power Supply 12 VDC ± 10%
Power Consumption < 5 W
Operating Temp. -30℃-(+60)℃, 10%-90%RH
